Name: SMQ-III Precision Cutting Machine A
Brand: Senmei
SKU: SMQ-III
Availability: InStock

Overview

Eight cuts per cycle, calibrated for short-format tubes.

The Senmei SMQ-III is a multi-tool precision cutting machine designed for short-format paper tubes — the kind of cut that a single-blade cutter handles too slowly for high-volume production. The SMQ-III indexes up to 8 segments per cycle on Ø 50–160 mm tubes up to 600 mm long, with length accuracy below 0.5 mm across every cut.

Minimum cut length is 75 mm, making the SMQ-III the standard cutting station for potato chip cans, nut cans, and short-format industrial cores. Throughput holds at 20–25 pieces per minute. Recipe parameters — blade depth, indexing speed, clamp pressure — are stored per stock and surface on the HMI for fast changeover.

CE certified 8 pcs / cycle Ø 50–160 mm 20–25 pcs/min < 0.5 mm accuracy

Request a quote Download spec sheet (PDF)

Key features

Built around uptime, not just speed.

8 segments per cycle. Multi-blade cutting head indexes up to 8 segments in a single cycle — replaces 8 single-blade cuts.
Sub-0.5 mm length accuracy. Recipe-driven indexing validated across 200+ installations in snack and industrial lines.
Short-format specialist. Minimum cut length of 75 mm, ideal for snack cans and short industrial cores.
Wide diameter range. Handles Ø 50 mm to Ø 160 mm tubes without retooling the head.
Quick-change blade. Blade swap in under 10 minutes; recipe auto-loads blade type, depth, and feed rate.
Touchscreen HMI. 10-inch industrial panel with multi-language UI, recipe library, and on-screen troubleshooting.
Safety-integrated guarding. Category 3 PL d safety circuit, CE-marked.

Trade information.

HS Code	8441.80 (other machinery for making up paper pulp, paper or paperboard)
Minimum order quantity (MOQ)	1 unit
Lead time	30–60 working days after deposit (confirmed per inquiry)
Payment terms	T/T 30% deposit + 70% balance after factory acceptance test; L/C at sight for large orders
Incoterms	FOB Qingdao (default) · CIF · CFR · DAP (door-to-door)
Packaging	Fumigation-free wooden case, anti-rust film, desiccant, foam-padded impact points; one standard machine per 20'GP
Loading port	Qingdao Port, Shandong Province, China
Country of origin	China
Certifications	CE marking (per shipment), ISO 9001 (manufacturer)
Warranty	12 months limited on main components; wear parts excluded
Spare parts availability	5 years from shipment date
Installation & training	One-for-one on-site engineer dispatch (quoted separately); remote video support included free first year
Documentation	Commercial invoice, packing list, certificate of origin (Form A / E / F), CE declaration, fumigation certificate

For accurate FOB pricing, CIF quote to your destination port, and door-to-door delivery to your facility, contact Senmei with your destination country and tube specifications. Reply within 24 hours on business days via WhatsApp or email.

Technical specifications

Standard configuration.

Model	SMQ-III
Tube diameter	Ø 50 – 160 mm
Tube length	≤ 600 mm
Applicable label thickness	100 – 120 gsm (Ø 30 – 75) / 100 – 157 gsm (Ø 80 – 160)
Cutting precision	< 0.5 mm
Maximum cutting quantity	8 pcs
Minimum recutting length	75 mm
Production speed	20 – 25 pieces per minute
Air pressure	0.5 MPa
Rated power	2.2 kW
Power supply	Selectable voltage
Operator	1 person
Machine footprint	2,680 × 1,530 × 1,500 mm
Weight	780 kg

Working principle

How the SMQ-III runs.

Tubes are loaded into the hopper by an operator or upstream spiral winder. A servo-driven feed carriage picks up the longest tube, indexes it to the multi-blade cutting bay, and holds it under clamp pressure. The multi-blade head descends at recipe-controlled depth, indexes along the tube length, and cuts up to 8 segments in a single cycle.

Cut segments are released onto the takeaway conveyor and the carriage indexes to the next tube. Recipe parameters — blade depth, indexing speed, clamp pressure, segment count — are stored per tube diameter and length. The HMI surfaces live production count, reject count, blade life remaining, and current recipe. Blade wear is logged automatically and a service alert fires when it's time to swap.

Applications

Where the SMQ-III fits.

Potato chip cans. Ø 73–80 mm × 200–280 mm short-format cans at 22 pieces per minute.
Nut and seed cans. Ø 100 mm × 200 mm cans for cashews, almonds, sunflower seeds, pistachios.
Snack pellets. Ø 60 mm × 180 mm cans for popcorn, cheese balls, extruded snacks.
Short industrial cores. Ø 50–160 mm cores up to 600 mm for tape, label stock, and small-format film rolls.
Confectionery tubes. Ø 50 mm × 150 mm candy and chocolate tubes with high-volume production.

Why Senmei

Three reasons customers keep coming back.

01

Tuned to your stock, not ours.

Every SMQ-III ships with a recipe card for your specific tube diameter, length, and stock. Blade depth, indexing speed, and clamp pressure are dialed in before crating.

02

Tested on your tubes, in our factory.

Senmei engineers run a factory acceptance test with your stock and verify length accuracy before the machine ships.

03

Support that doesn't expire.

Lifetime remote diagnostics, on-site engineer dispatch available globally, and a 12-month warranty — extended to 24 months on request.
